SGRV Gauge Root Valves
SGRV Gauge Root Valves
Access our complete line of gauge root valves constructed from durable stainless steel. Our selection features 1/2″ and 3/4″ NPT connections. Browse below to instantly request a quote or purchase the gauge root valves you need.
Looking for Swagelok® alternatives? Enter a part number in our search to find compatible alternatives.
Specifications
| End Size 2 | 44198in |
|---|---|
| End Type | Male National Pipe Thread (MNPT) |
| End Type 2 | Female National Pipe Thread (FNPT) |
| Inch/Metric | Inch |
| Operating Pressure [Max] | 413bar, 6000psig |
| Superlok Part Type | Root Valve |
| Temperature Rating with Polytetrafluoroethylene (PTFE) Packing | -54 to 232ºC, -65 to 450ºF |
Available Sizes
SGRV-MF-8N SGRV Gauge Root Valves
SGRV 1/2 in. Male National Pipe Taper (MNPT) Thread x 1/2 in. Female National Pipe Taper (FNPT) Thread, 6000 psi Working Pressure [Max] Gauge Root Valve
SGRV-MF-8N-MR SGRV Gauge Root Valves
SGRV 1/2 in. Male National Pipe Taper (MNPT) Thread x 1/2 in. Female National Pipe Taper (FNPT) Thread, National Association of Corrosion Engineers (NACE)-Rated, 6000 psi Working Pressure [Max] Process End Connection Size Gauge Root Valve
SGRV-MF-12N-8N SGRV Gauge Root Valves
SGRV 3/4 in. Male National Pipe Taper (MNPT) Thread x 1/2 in. Female National Pipe Taper (FNPT) Thread, 6000 psi Working Pressure [Max] Gauge Root Valve
